Key Takeaways & Executive Findings
- •• • The TD3-R_LADRC strategy reduces DC bus voltage fluctuations by optimizing both observer and controller bandwidths via TD3, achieving faster convergence than fixed-parameter LADRC; this directly mitigates the risk of converter shutdown or reduced battery lifetime in microgrids with high renewable penetration. • • The improved LESO estimates the disturbance derivative and applies order reduction to known states, enhancing observation accuracy without increasing system order; this lowers computational burden and parameter tuning complexity, enabling practical deployment on embedded controllers with limited resources. • • Comparative experiments under renewable intermittency and load steps show TD3-R_LADRC outperforms dual-loop PI and conventional LADRC in disturbance rejection and robustness, with reduced settling time and overshoot; this translates to higher power quality and fewer protection trips in commercial energy storage systems. • • The TD3 algorithm addresses Q-value overestimation and local optima issues inherent in DDPG, as evidenced by stable training convergence and improved control performance; this provides a reliable reinforcement learning framework for online parameter adaptation in safety-critical power electronics.
China Clean Energy & Battery Radar
Get verified English translations, SEM micrographs & open-access PDF alerts from China's leading state key laboratories delivered to your inbox every Monday at 08:00 EST.
Abstract
Output voltage fluctuations in DC microgrids arise from renewable generation intermittency, spatiotemporal load variations, and external disturbances. This study proposes a reconstructed linear active disturbance rejection control strategy (TD3-R_LADRC) that integrates a twin delayed deep deterministic policy gradient (TD3) algorithm to enhance the DC bus voltage stabilization capability of battery energy storage interface converters. The improved linear extended state observer (LESO) estimates the derivative of the total disturbance and applies order reduction to known state variables, achieving faster and more accurate tracking and compensation without increasing system order. Frequency-domain performance and stability analyses are conducted for the proposed strategy. The TD3 reinforcement learning algorithm then optimizes the observer bandwidth and controller bandwidth of the improved LADRC, enabling precise observation and rapid convergence. Digital simulations and low-power experiments compare the proposed TD3-R_LADRC against conventional LADRC and dual-loop PI control under various operating conditions. Results demonstrate that TD3-R_LADRC exhibits superior disturbance rejection, stability, and robustness against renewable output uncertainty, load fluctuations, and external disturbances, effectively improving frequency stability control and offering theoretical and engineering value for energy storage converter applications.
1. Introduction
Commercial DC microgrids integrating high shares of solar photovoltaic generation face persistent bus voltage instability due to the stochastic and intermittent nature of renewable resources, compounded by unpredictable load profiles. Conventional dual-loop PI controllers struggle to balance response speed and stability, often exhibiting delayed transient recovery and limited disturbance rejection. While linear active disturbance rejection control (LADRC) offers a model-independent alternative by actively estimating and compensating total disturbances, its performance is constrained by fixed observer and controller bandwidths that cannot adapt to time-varying operating conditions. Prior attempts to enhance LADRC through nonlinear functions or higher-order observers have increased parameter tuning complexity and computational overhead, hindering practical implementation.
This study addresses the parameter rigidity bottleneck by introducing a twin delayed deep deterministic policy gradient (TD3) algorithm to dynamically optimize the bandwidths of a reconstructed LADRC. The proposed TD3-R_LADRC first modifies the linear extended state observer (LESO) to estimate the disturbance derivative and reduce the order of known state variables, improving observation speed and accuracy without elevating system order. The TD3 agent then learns optimal bandwidth parameters through continuous interaction with the converter environment, overcoming the Q-value overestimation and local optima issues of DDPG. Frequency-domain analysis and experimental validation confirm that TD3-R_LADRC achieves superior disturbance rejection, stability, and robustness compared to conventional LADRC and dual-loop PI, offering a practical pathway for enhancing energy storage converter performance in uncertain microgrid conditions.
Loading authentic research manuscript (Pages 1–5)...
MA Youjie, YAN Fengxiang, ZHOU Xuesong, TAO Long, WANG Xinyue, CHEN Yunfei (2026). Improved Linear Active Disturbance Rejection Control of Energy Storage Converters Based on the TD3 Algorithm. Acta Energiae Solaris Sinica. https://doi.org/10.19912/j.0254-0096.tynxb.202608_9662
Research & Educational Purpose Only: The translations, structured abstracts, analytical annotations, and data reports provided by SinoGreenTechare intended exclusively for academic research, internal corporate R&D, and educational benchmarking. They do not constitute formal engineering, chemical safety, legal, or professional advice.
Copyright & Intellectual Property Notice: Original copyright of the underlying source articles and experimental data remains with the respective authors, institutions, and original publishing journals. SinoGreenTech claims intellectual property only over its proprietary translations, analytical syntheses, and AEO structured enhancements in accordance with international fair use and academic citation principles.
Frequently Asked Questions
What specific failure mechanisms in conventional LADRC does the TD3-R_LADRC strategy mitigate under renewable intermittency?
Conventional LADRC suffers from fixed observer and controller bandwidths that cannot adapt to rapid disturbances, leading to sluggish disturbance estimation and residual voltage oscillations. The TD3-R_LADRC dynamically tunes these bandwidths via reinforcement learning, reducing settling time and overshoot. Experimental comparisons show that under step load changes, TD3-R_LADRC achieves faster convergence and lower steady-state error than LADRC, effectively preventing bus voltage excursions that could trigger protective shutdowns.
How does the improved LESO achieve order reduction without increasing system complexity, and what is the impact on computational load?
The improved LESO estimates the derivative of the total disturbance and applies order reduction to known state variables, eliminating the need for higher-order observer structures. This maintains the original system order while enhancing observation accuracy. Consequently, the computational burden remains comparable to standard LESO, making it suitable for real-time implementation on digital signal processors used in commercial converters.
What evidence demonstrates that TD3 outperforms DDPG in optimizing LADRC parameters for this application?
TD3 addresses DDPG's Q-value overestimation by employing twin critics and delayed policy updates, which prevents local optima and stabilizes training. In this study, TD3-R_LADRC exhibited consistent convergence and superior control performance across varying operating conditions, whereas DDPG-based LADRC showed parameter oscillations and suboptimal disturbance rejection. The experimental results confirm that TD3 yields more reliable bandwidth optimization, leading to improved voltage regulation.
What are the scalability bottlenecks for deploying TD3-R_LADRC in multi-converter microgrids?
Scalability is constrained by the need for centralized training of the TD3 agent, which requires communication and coordination among converters. However, the improved LESO's reduced computational load and the TD3's sample efficiency enable distributed implementation with local measurements. Future work should address multi-agent coordination and communication delays to extend the strategy to large-scale microgrids.
How does the proposed control strategy impact the lifetime and cost of battery energy storage systems?
By reducing bus voltage fluctuations and settling time, TD3-R_LADRC minimizes stress on battery cells caused by frequent charge-discharge cycles and overvoltage events. This can extend battery lifetime and reduce replacement costs. Although the TD3 algorithm adds computational overhead, the use of low-power embedded processors keeps implementation costs marginal compared to the benefits of improved reliability and reduced maintenance.
