Key Takeaways & Executive Findings
- •• • On rainy days, the proposed model reduces ERMSE and EMAE by 49.3% and 51.9% on average compared to a single BiLSTM model, directly improving forecast reliability under volatile weather—critical for grid frequency regulation and reducing reserve capacity requirements. • • The entropy-based causal feature extraction method quantifies nonlinear coupling among meteorological factors, eliminating redundant inputs that plague linear correlation methods like Pearson coefficients, thereby enhancing feature selection quality and model generalization. • • The parallel BiLSTM and TCN-Transformer architecture captures multi-scale temporal dependencies: BiLSTM handles short-term fluctuations, while TCN-Transformer extracts local patterns and long-range dependencies, achieving superior performance over single models in all three weather scenarios. • • The improved Q-learning algorithm with a cosine-modulated dynamic reward-penalty mechanism adaptively adjusts sub-model weights, overcoming the static weight limitations of error inverse and mean fusion methods, and preventing premature convergence or local optima during training.
China Clean Energy & Battery Radar
Get verified English translations, SEM micrographs & open-access PDF alerts from China's leading state key laboratories delivered to your inbox every Monday at 08:00 EST.
Abstract
Photovoltaic (PV) power forecasting is challenged by redundant meteorological features, insufficient multi-timescale dynamic response, and the lack of dynamic adaptability in hybrid models. This study proposes an ultra-short-term forecasting framework integrating causal feature extraction with an improved Q-learning (IQ-L) algorithm. First, an entropy-based causal feature extraction method quantifies nonlinear coupling between meteorological variables and PV power, filtering key factors. Second, a parallel prediction model combining bidirectional long short-term memory (BiLSTM) and TCN-Transformer captures short-term fluctuations, local patterns, and long-term dependencies, enabling multi-scale feature fusion. Third, an improved Q-learning algorithm with a dynamic reward-penalty mechanism, incorporating a cosine factor, iteratively adjusts the weights of sub-models to produce the final forecast. Validation under three typical weather conditions shows that the proposed model achieves stable performance. On rainy days, compared with a single BiLSTM model, the proposed method reduces ERMSE and EMAE by an average of 49.3% and 51.9%, respectively, demonstrating enhanced accuracy and generalization. The framework addresses the limitations of static weight allocation and single reward mechanisms in existing hybrid approaches, offering a robust solution for grid dispatch and energy storage optimization.
1. Introduction
Existing commercial PV forecasting solutions predominantly rely on static weight allocation or simple ensemble methods, such as error inverse weighting or mean fusion. These approaches are inherently vulnerable to outliers and lack dynamic responsiveness to rapidly changing meteorological conditions. Furthermore, traditional feature extraction techniques—like Pearson correlation—only capture linear relationships, failing to quantify the nonlinear coupling between meteorological variables and PV power output. This limitation leads to redundant inputs, increased model complexity, and degraded prediction accuracy, particularly under highly variable weather such as rain or cloud cover. Consequently, grid operators face challenges in scheduling and energy storage optimization, as forecast errors propagate into dispatch decisions.
To address these bottlenecks, this study introduces a hybrid forecasting framework that integrates causal feature extraction with an improved Q-learning algorithm. The entropy-based causal method filters key meteorological factors by quantifying nonlinear interactions, reducing input dimensionality while preserving critical information. A parallel BiLSTM and TCN-Transformer model captures multi-scale temporal features, and an improved Q-learning algorithm with a cosine-modulated dynamic reward-penalty mechanism adaptively adjusts the contribution of each sub-model. This protocol directly tackles the static weight and single reward limitations of prior work, delivering a 49.3% and 51.9% reduction in ERMSE and EMAE on rainy days compared to a single BiLSTM, thereby enhancing forecast stability and generalization for real-world deployment.
Loading authentic research manuscript (Pages 1–5)...
ZHANG Li, LIU Jiawei, SUN Shuyan, ZHANG Tao, ZHANG Hongwei (2026). Ultra-Short-Term Photovoltaic Power Forecasting Based on Causal Feature Extraction and an Improved Q-Learning Algorithm. Acta Energiae Solaris Sinica. https://doi.org/10.19912/j.0254-0096.tynxb.202608_9677
Research & Educational Purpose Only: The translations, structured abstracts, analytical annotations, and data reports provided by SinoGreenTechare intended exclusively for academic research, internal corporate R&D, and educational benchmarking. They do not constitute formal engineering, chemical safety, legal, or professional advice.
Copyright & Intellectual Property Notice: Original copyright of the underlying source articles and experimental data remains with the respective authors, institutions, and original publishing journals. SinoGreenTech claims intellectual property only over its proprietary translations, analytical syntheses, and AEO structured enhancements in accordance with international fair use and academic citation principles.
Frequently Asked Questions
What specific failure mechanisms in existing hybrid forecasting models does the proposed IQ-L algorithm address?
Existing hybrid models often use static weight allocation (e.g., error inverse method) that is sensitive to outliers and lacks dynamic adjustment, leading to degraded accuracy during rapid weather transitions. Additionally, single reward mechanisms in Q-learning can cause insufficient exploration in early training or premature convergence to local optima. The proposed IQ-L algorithm introduces a cosine-modulated dynamic reward-penalty mechanism that adaptively balances exploration and exploitation, and iteratively adjusts sub-model weights based on prediction error feedback, thereby mitigating these failure modes.
How does the entropy-based causal feature extraction improve upon traditional linear correlation methods like Pearson coefficients?
Pearson coefficients only capture linear relationships and cannot quantify nonlinear coupling among multiple meteorological variables. The entropy-based causal method computes causal entropy to measure nonlinear interactions and indirect influences, enabling the selection of key meteorological factors that are strongly causally linked to PV power fluctuations. This reduces feature redundancy and enhances the model's ability to generalize under complex weather conditions, as evidenced by improved performance across three typical weather scenarios.
What are the scalability and computational bottlenecks when deploying this model for real-time ultra-short-term forecasting?
The parallel BiLSTM and TCN-Transformer architecture increases computational load compared to single models, potentially challenging real-time deployment on edge devices. However, the causal feature extraction reduces input dimensionality, partially offsetting this. The IQ-L algorithm requires iterative training, but once trained, inference is fast. For scalability, the model can be parallelized on GPUs, and the dynamic weight adjustment is lightweight. Field validation on a 13-month dataset (as per the paper's experimental setup) demonstrates stable performance, but further optimization is needed for resource-constrained environments.
How does the model perform under extreme weather conditions, such as heavy rain or rapid cloud transients, compared to benchmark models?
Under rainy conditions, the proposed model reduces ERMSE and EMAE by 49.3% and 51.9% on average compared to a single BiLSTM model. This improvement is attributed to the multi-scale feature fusion and dynamic weight adjustment, which better capture rapid fluctuations. The TCN-Transformer component excels at extracting local patterns and long-term dependencies, while the IQ-L algorithm adapts weights in real time. However, the paper does not provide specific metrics for extreme events like thunderstorms; further testing under such scenarios is recommended.
What is the economic impact of the reported accuracy improvement on grid dispatch and energy storage optimization?
A 49.3% reduction in ERMSE and 51.9% in EMAE directly lowers forecast uncertainty, enabling more accurate scheduling of reserve capacity and reducing reliance on fast-ramping fossil fuel plants. For energy storage, improved forecasts optimize charge-discharge cycles, extending battery life and reducing operational costs. While the paper does not provide a detailed cost-benefit analysis, the accuracy gains translate to fewer penalties for deviation in electricity markets and improved integration of PV into the grid, potentially saving millions in balancing costs annually for large-scale deployments.
