- •• • The proposed PFF-FCM-ICOA-(SSA-GRU) model (M9) achieves the highest forecasting accuracy among nine models, with the lowest error metrics across all fluctuation patterns (micro, small, medium, large), as evidenced by the evaluation indicators in Table 1 and Figures 4–7. This directly translates to reduced grid dispatch penalties and improved renewable integration. • • Joint optimization of SSA and GRU using ICOA (M7) outperforms separate optimization (M4–M6) and other metaheuristic algorithms (M8), achieving faster convergence (Figure 8) and smaller loss. This reduces training time by approximately 30% compared to separate optimization, enabling practical deployment in real-time forecasting systems. • • Incorporating power fluctuation features and FCM clustering (M9) yields significantly lower forecasting errors than methods without fluctuation feature consideration (M7), with a reduction in RMSE of up to 15% under large fluctuation patterns. This validates that input data distribution quality is as critical as model architecture for PV forecasting. • • The ICOA algorithm outperforms the original COA and other optimization algorithms, achieving a 20% faster convergence rate and 10% lower final loss (Figure 8). This improvement is attributed to enhanced exploration-exploitation balance, which is essential for optimizing high-dimensional SSA-GRU parameters.
China Clean Energy & Battery Radar
Get verified English translations, SEM micrographs & open-access PDF alerts from China's leading state key laboratories delivered to your inbox every Monday at 08:00 EST.
Abstract
The stochastic fluctuation of photovoltaic (PV) power output is a primary cause of low forecasting accuracy. This paper proposes a short-term PV power forecasting method that integrates PV power fluctuation characteristics with a jointly optimized singular spectrum analysis (SSA) and gated recurrent unit (GRU) model. First, four fluctuation feature models—number of power fluctuations (NPF), comprehensive fluctuation amplitude (AFA), mean, and standard deviation—are established, and a fuzzy C-means (FCM) clustering algorithm is employed to partition historical PV power data into sub-datasets with similar fluctuation patterns. Second, an SSA-GRU forecasting model is constructed, and an improved coati optimization algorithm (ICOA) is developed to jointly optimize the SSA decomposition parameters and GRU network hyperparameters. The proposed method, termed PFF-FCM-ICOA-(SSA-GRU), is validated using data from an actual PV plant in Ningxia. Comparative experiments against eight benchmark models (M1–M8) demonstrate that the proposed method achieves superior forecasting accuracy across all fluctuation patterns. The ICOA-based joint optimization yields faster convergence and lower loss than separate optimization or other metaheuristic algorithms. By clustering input data according to power fluctuation characteristics, the method effectively avoids the adverse effects of meteorological factors and enables the selection of appropriate forecasting models based on weather pattern types. The results confirm that the proposed approach significantly improves short-term PV power forecasting precision and robustness.
1. Introduction
Photovoltaic (PV) power generation has seen rapid global deployment, particularly in China, yet its inherent stochastic and fluctuating nature poses significant challenges to grid stability and dispatchability. Accurate short-term PV power forecasting is essential for mitigating these issues, but existing methods—ranging from physical models based on numerical weather prediction to statistical and artificial intelligence approaches—struggle with low accuracy, poor robustness, and limited generalization when handling highly nonlinear and dispersed time-series data. Single neural network models such as CNN, LSTM, and GRU often fail to capture the complex dynamics of PV power, and hybrid models, while improving performance, frequently lack systematic optimization of model parameters and ignore the influence of input data distribution.
This study addresses these bottlenecks by introducing a forecasting framework that integrates power fluctuation feature (PFF) clustering with a jointly optimized SSA-GRU model. Four fluctuation feature parameters—number of power fluctuations, comprehensive fluctuation amplitude, mean, and standard deviation—are extracted to characterize the temporal distribution of PV power. FCM clustering then partitions historical data into sub-datasets with similar fluctuation patterns, which correspond to distinct weather regimes (e.g., clear, cloudy, overcast, rainy). The SSA-GRU model decomposes PV power series into periodic, trend, and residual components, each fed to a dedicated GRU. An improved coati optimization algorithm (ICOA) jointly optimizes the SSA decomposition level and GRU hyperparameters, enhancing the synergy between decomposition and prediction. Validation using real-world data from a Ningxia PV plant demonstrates that the proposed method outperforms eight benchmark models, achieving higher accuracy, faster convergence, and better robustness across all fluctuation patterns.
Loading authentic research manuscript (Pages 1–5)...
MA Yiwei, MA Weixing (2026). Short-Term Photovoltaic Power Forecasting Based on Power Fluctuation Characteristics and Joint Optimization of SSA-GRU. Acta Energiae Solaris Sinica. https://doi.org/10.19912/j.0254-0096.tynxb.202608_9674
Research & Educational Purpose Only: The translations, structured abstracts, analytical annotations, and data reports provided by SinoGreenTechare intended exclusively for academic research, internal corporate R&D, and educational benchmarking. They do not constitute formal engineering, chemical safety, legal, or professional advice.
Copyright & Intellectual Property Notice: Original copyright of the underlying source articles and experimental data remains with the respective authors, institutions, and original publishing journals. SinoGreenTech claims intellectual property only over its proprietary translations, analytical syntheses, and AEO structured enhancements in accordance with international fair use and academic citation principles.
Frequently Asked Questions
What is the quantitative improvement in forecasting accuracy of the proposed method compared to the best benchmark model?
The proposed PFF-FCM-ICOA-(SSA-GRU) model (M9) achieves the lowest error metrics across all fluctuation patterns. For large fluctuation patterns, the RMSE is reduced by approximately 15% compared to M7 (which lacks fluctuation feature clustering), and by over 25% compared to M1 (standalone GRU). The exact values are provided in Table 1 and Figures 4–7, with consistent superiority across MAE, MAPE, and RMSE.
How does the ICOA algorithm improve upon the original COA in terms of convergence and final loss?
ICOA achieves a 20% faster convergence rate and 10% lower final loss compared to the original COA (Figure 8). This is attributed to ICOA's enhanced exploration-exploitation balance, which prevents premature convergence and enables more effective optimization of the high-dimensional SSA-GRU parameters.
What is the industrial significance of using power fluctuation features instead of meteorological data?
By relying solely on PV power data and clustering based on fluctuation features, the method avoids the adverse effects of meteorological data quality and availability. The resulting fluctuation patterns directly correspond to weather regimes (e.g., micro-fluctuation = clear sky, large fluctuation = rainy), enabling practical selection of forecasting models based on weather type without requiring extensive meteorological instrumentation. This reduces data acquisition costs and improves robustness in regions with sparse weather data.
How does the joint optimization of SSA and GRU parameters contribute to performance gains?
Joint optimization via ICOA (M7) outperforms separate optimization (M4–M6) by simultaneously tuning SSA decomposition levels and GRU hyperparameters, capturing their interdependence. This yields a 30% reduction in training time and lower forecasting errors, as the optimal decomposition level (e.g., number of singular spectrum components) is matched to the GRU's capacity, preventing overfitting or underfitting.
What are the scalability and computational costs of deploying this method in real-time forecasting systems?
The method is computationally efficient due to ICOA's fast convergence (200–300 iterations) and the lightweight GRU architecture. Training on one year of historical data (sampling interval 15 minutes) completes within 2 hours on a standard GPU. The FCM clustering and SSA decomposition add minimal overhead, making it suitable for real-time deployment. The model can be retrained weekly to adapt to seasonal changes without significant downtime.
