Key Takeaways & Executive Findings
- •• • The WAIES cooperative operation reduced total system cost by 6.58% and carbon trading cost by 1.64% compared to independent operation, while achieving 100% renewable energy consumption. This demonstrates that cross-regional multi-energy sharing can simultaneously improve economic and environmental performance, a critical finding for scaling low-carbon energy networks. • • The asymmetric Nash bargaining model allocates profits proportional to each entity's contribution, with a deliberate bias toward energy suppliers. This design addresses fairness concerns in cooperative games, potentially increasing participation incentives and long-term stability of multi-energy sharing alliances. • • The two-stage robust-Nash optimization method, solved via ADMM and C&CG, ensures reliable decision-making under source-load uncertainty. Out-of-sample validation confirms its strategy adaptability, making it suitable for real-world deployment where renewable generation and demand forecasts are imperfect. • • The framework's scalability to large-scale interconnected energy systems is constrained by potential non-convexity in the bargaining function as the number of members increases, which could lead to negotiation infeasibility. This identifies a key research gap for extending the approach to urban or industrial-scale applications.
China Clean Energy & Battery Radar
Get verified English translations, SEM micrographs & open-access PDF alerts from China's leading state key laboratories delivered to your inbox every Monday at 08:00 EST.
Abstract
This study addresses the cooperative game problem of multi-energy sharing among cross-regional integrated energy systems (IESs) under source-load uncertainty. A wide-area IES (WAIES) multi-energy sharing cooperative operation model is constructed, incorporating electric-thermal-gas coupling, renewable generation, and energy conversion devices. To ensure fair profit distribution among resource-endowed entities, a Nash bargaining model based on asymmetric bargaining is proposed, decomposing the optimization into cooperative cost minimization and profit allocation subproblems. A day-ahead and real-time two-stage robust-Nash optimization method is developed to protect data privacy and mitigate uncertainty, solved via alternating direction method of multipliers (ADMM) and column-and-constraint generation (C&CG). Case studies demonstrate that compared to independent operation, the WAIES reduces total cost by 6.58%, carbon trading cost by 1.64%, and achieves 100% renewable energy consumption. The asymmetric bargaining mechanism correlates profit allocation with contribution, incentivizing cooperation while ensuring fairness. The two-stage robust optimization enhances strategy adaptability under uncertainty, validated through out-of-sample analysis. The framework shows potential for extension to urban agglomeration energy coordination and industrial park cascade optimization, though scalability challenges regarding convexity and negotiation feasibility in large-scale systems remain for future work.
1. Introduction
Existing multi-energy sharing mechanisms are predominantly confined to single integrated energy systems (IESs), failing to address cross-regional energy scheduling and the complex synergies required for wide-area coordination. Traditional cooperative game approaches, such as coalition games, often lack unique optimal solutions and suffer from fairness disputes, while conventional Nash bargaining models inadequately capture contribution disparities arising from heterogeneous resource endowments. Furthermore, source-load uncertainty from renewable generation and stochastic demand introduces dynamic imbalances that compromise the reliability of day-ahead scheduling and real-time operations. These limitations hinder the economic and low-carbon potential of interconnected energy networks.
This study proposes a robust-Nash optimization method based on asymmetric bargaining to overcome these bottlenecks. A wide-area IES (WAIES) cooperative operation model is established, integrating electric-thermal-gas coupling and multi-energy sharing. The asymmetric Nash bargaining model quantifies each entity's contribution, ensuring fair profit allocation and incentivizing cooperation. A two-stage robust optimization framework, solved via ADMM and C&CG, protects data privacy and enhances resilience against uncertainties. Case studies validate that the method reduces total cost by 6.58%, carbon trading cost by 1.64%, and achieves 100% renewable consumption, offering a scalable pathway for urban and industrial energy coordination.
Loading authentic research manuscript (Pages 1–5)...
HUANG Liyan, AI Xin, WANG Zhe (2026). Robust-Nash Optimization Method for Multi-Energy Sharing in Wide-Area Integrated Energy Systems Based on Asymmetric Bargaining. Acta Energiae Solaris Sinica. https://doi.org/10.19912/j.0254-0096.tynxb.202608_9693
Research & Educational Purpose Only: The translations, structured abstracts, analytical annotations, and data reports provided by SinoGreenTechare intended exclusively for academic research, internal corporate R&D, and educational benchmarking. They do not constitute formal engineering, chemical safety, legal, or professional advice.
Copyright & Intellectual Property Notice: Original copyright of the underlying source articles and experimental data remains with the respective authors, institutions, and original publishing journals. SinoGreenTech claims intellectual property only over its proprietary translations, analytical syntheses, and AEO structured enhancements in accordance with international fair use and academic citation principles.
Frequently Asked Questions
What are the failure mechanisms of the proposed robust-Nash optimization under extreme uncertainty scenarios?
The two-stage robust optimization considers worst-case realizations of renewable generation and load, ensuring feasibility within a predefined uncertainty set. However, if actual deviations exceed the set boundaries, the system may incur higher operational costs or violate constraints. The out-of-sample analysis confirms strategy adaptability, but extreme events beyond the uncertainty set could degrade performance. Future work should dynamically adjust uncertainty sets based on real-time data.
How does the asymmetric bargaining model ensure fair profit allocation compared to traditional Nash bargaining?
The asymmetric model weights each entity's bargaining power by its contribution to the coalition, quantified through energy supply, flexibility, or carbon reduction. This creates a positive correlation between contribution and profit share, with a slight bias toward energy suppliers to incentivize participation. In contrast, symmetric Nash bargaining assumes equal bargaining power, which may undercompensate critical contributors and destabilize cooperation.
What are the scalability bottlenecks when extending this framework to large-scale energy systems?
As the number of participating entities increases, the multi-energy coupling constraints grow exponentially, potentially rendering the bargaining function non-convex. This can lead to negotiation infeasibility or multiple equilibria, undermining the uniqueness of the Nash solution. Additionally, computational complexity of ADMM and C&CG escalates, requiring distributed algorithms with convergence guarantees for large-scale deployment.
What is the cost parity of the proposed method against conventional independent operation?
The WAIES cooperative operation reduces total system cost by 6.58% and carbon trading cost by 1.64% relative to independent operation. These savings stem from enhanced renewable utilization (100% consumption) and optimized multi-energy scheduling. The method achieves cost parity with legacy systems while providing additional environmental benefits, making it economically viable for wide-area deployment.
How does the two-stage robust optimization handle data privacy among participating entities?
The ADMM algorithm decomposes the optimization into subproblems solved locally by each entity, exchanging only limited boundary information (e.g., power/heat interchange) rather than full operational data. This preserves privacy while coordinating the coalition. The C&CG algorithm further ensures robust feasibility without centralizing sensitive data, addressing confidentiality concerns in multi-party energy sharing.
