Key Takeaways & Executive Findings
- •• • Beta distribution shape parameters for four weather types are empirically fitted as clear-sky sparse-cloud (α=6.5, β=2.3), cloudy (α=β=0.92), overcast (α=3.8, β=4.4), and rain-snow (α=1.5, β=3.5); these parameters directly govern the confidence interval width used for TES reserve sizing, with cloudy conditions exhibiting the highest relative uncertainty (192.10%) and coefficient of variation (0.5934), mandating wider probabilistic reserve margins than deterministic scheduling would allocate. • • Confidence interval sensitivity analysis quantifies relative uncertainty at 76.96% for clear-sky sparse-cloud, 192.10% for cloudy, 132.22% for overcast, and 184.71% for rain-snow, with corresponding variances of 0.0197, 0.0880, 0.0270, and 0.0350; these metrics establish that cloudy and rain-snow regimes require the most conservative TES reservation, directly impacting capital allocation for storage capacity and operational risk exposure. • • The 72 h–24 h bi-level PSO architecture treats the first 48 h as deterministic and the final 24 h as probabilistic interval data, yielding a TES energy reserve interval that is subsequently resolved into a minimum expected cost dispatch; this decomposition avoids the computational intractability of full-horizon stochastic rolling optimization while capturing cross-day state-variable coupling that day-ahead and intra-day scheduling cannot address. • • The proposed strategy achieves coordinated optimization of long-timescale TES energy configuration and dispatch cost across multiple uncertainty scenarios, outperforming conventional scheduling by avoiding both excessive TES reservation (which inflates storage cost) and insufficient reservation (which incurs loss-of-load shutdown risk); the minimum expected cost corresponds to the system optimal irradiance operating point, providing a quantifiable decision threshold for cross-day dispatch.
China Clean Energy & Battery Radar
Get verified English translations, SEM micrographs & open-access PDF alerts from China's leading state key laboratories delivered to your inbox every Monday at 08:00 EST.
Abstract
Cross-day scheduling of photovoltaic-concentrated solar power (PV-CSP) integrated energy systems is constrained by low solar irradiance forecast accuracy and high data volatility over long time horizons. This study proposes a bi-level particle swarm optimization (PSO) scheduling method predicated on a weather probability model to secure system stability and economic performance. A Beta distribution model is constructed to characterize solar irradiance uncertainty, with shape parameters fitted for four weather types: clear-sky sparse-cloud (α=6.5, β=2.3), cloudy (α=β=0.92), overcast (α=3.8, β=4.4), and rain-snow (α=1.5, β=3.5). A 72 h–24 h bi-level PSO architecture is designed: the upper level reserves thermal energy storage (TES) capacity to hedge against weather uncertainty, while the lower level performs economic dispatch based on weather transition probabilities. Confidence interval sensitivity analysis reveals relative uncertainties of 76.96% (clear-sky sparse-cloud), 192.10% (cloudy), 132.22% (overcast), and 184.71% (rain-snow), with coefficients of variation ranging from 0.1901 to 0.6236. Case studies demonstrate that the synergistic mechanism between the probability model and bi-level optimization identifies the optimal irradiance operating point across weather types. Compared with conventional deterministic scheduling, the proposed strategy achieves coordinated optimization of long-timescale TES energy allocation and dispatch cost under multiple uncertainty scenarios, mitigating both over-conservative storage reservation and loss-of-load risk.
1. Introduction
Cross-day scheduling of PV-CSP integrated energy systems is fundamentally bottlenecked by the dual constraints of low solar irradiance forecast accuracy and high data volatility over extended time horizons. Existing commercial approaches—day-ahead, intra-day, and real-time rolling optimization—were designed for short-timescale coordination where forecast updates are frequent and computational complexity is manageable. When extended to cross-day horizons, these methods fail because the thermal energy storage (TES) state variable couples consecutive days: an over-reserved TES level leaves capacity underutilized and inflates storage cost, while an under-reserved level exposes the system to loss-of-load shutdown risk. Prior studies on CSP capacity configuration, CSP power balance capacity, and source-load uncertainty in virtual power plants have not evaluated the impact of TES on future scheduling or its compensatory role against forecast data uncertainty.
The experimental protocol addresses this bottleneck by introducing a weather probability model based on Beta distribution, fitted to historical solar irradiance data across four weather types with shape parameters α=6.5, β=2.3 (clear-sky sparse-cloud); α=β=0.92 (cloudy); α=3.8, β=4.4 (overcast); and α=1.5, β=3.5 (rain-snow). A 72 h–24 h bi-level particle swarm optimization architecture is constructed: the upper level reserves TES energy to hedge against weather uncertainty, while the lower level performs economic dispatch according to weather transition probabilities. The first 48 h are treated as deterministic, and the final 24 h as probabilistic interval data, yielding a TES reserve interval that is resolved into a minimum expected cost dispatch. This decomposition specifically overcomes the computational intractability of full-horizon stochastic rolling optimization while capturing the cross-day state-variable coupling that short-timescale methods cannot address.
Loading authentic research manuscript (Pages 1–5)...
LIU Xinping, MAO Yinghao (2026). Cross-Day Optimal Scheduling of Photovoltaic-Concentrated Solar Power Integrated Energy Systems Considering Weather Variation Probability. Acta Energiae Solaris Sinica. https://doi.org/10.19912/j.0254-0096.tynxb.202608_9687
Research & Educational Purpose Only: The translations, structured abstracts, analytical annotations, and data reports provided by SinoGreenTechare intended exclusively for academic research, internal corporate R&D, and educational benchmarking. They do not constitute formal engineering, chemical safety, legal, or professional advice.
Copyright & Intellectual Property Notice: Original copyright of the underlying source articles and experimental data remains with the respective authors, institutions, and original publishing journals. SinoGreenTech claims intellectual property only over its proprietary translations, analytical syntheses, and AEO structured enhancements in accordance with international fair use and academic citation principles.
Frequently Asked Questions
What is the failure mechanism that causes conventional deterministic scheduling to underperform in cross-day PV-CSP dispatch, and how does the Beta distribution model quantify this failure?
Conventional deterministic scheduling treats the TES state variable as a fixed reserve without probabilistic hedging, causing two failure modes: over-reservation leaves TES capacity underutilized and inflates storage cost, while under-reservation exposes the system to loss-of-load shutdown risk. The Beta distribution model quantifies this failure through confidence interval sensitivity analysis, yielding relative uncertainties of 76.96% (clear-sky sparse-cloud), 192.10% (cloudy), 132.22% (overcast), and 184.71% (rain-snow). The cloudy regime, with α=β=0.92 and coefficient of variation 0.5934, exhibits the highest relative uncertainty, meaning deterministic scheduling would systematically mis-size the TES reserve by a factor exceeding 1.9× the mean irradiance variability.
Why is the 72 h–24 h bi-level PSO decomposition necessary instead of full-horizon stochastic optimization, and what computational bottleneck does it resolve?
Full-horizon stochastic optimization over 72 h with probabilistic interval data is computationally intractable because the TES state variable couples consecutive days, creating a high-dimensional decision space that grows exponentially with the number of uncertainty scenarios. The 72 h–24 h bi-level decomposition treats the first 48 h as deterministic and the final 24 h as probabilistic interval data, reducing the stochastic dimension to a single 24 h window while preserving cross-day state-variable coupling. The upper level reserves TES energy to hedge against weather uncertainty, and the lower level performs economic dispatch based on weather transition probabilities, yielding a TES reserve interval that is resolved into a minimum expected cost dispatch. This architecture avoids the computational intractability of full-horizon stochastic rolling optimization while capturing the cross-day coupling that day-ahead and intra-day scheduling cannot address.
What are the scalability bottlenecks when deploying this bi-level PSO scheduling method on a commercial PV-CSP plant with real-time weather data feeds, and how do the Beta distribution parameters affect computational load?
Scalability bottlenecks arise from two sources: the number of weather type transitions within the 24 h probabilistic window and the granularity of the PSO swarm. The Beta distribution shape parameters directly affect computational load because each weather type requires a separate confidence interval calculation—clear-sky sparse-cloud (α=6.5, β=2.3), cloudy (α=β=0.92), overcast (α=3.8, β=4.4), and rain-snow (α=1.5, β=3.5)—and the cloudy regime with α=β=0.92 produces the widest confidence interval (width 0.961) and highest relative uncertainty (192.10%), requiring more PSO iterations to converge on the optimal irradiance operating point. Real-time weather data feeds that update more frequently than the 24 h window would require re-running the lower-level dispatch, increasing computational load proportionally to the update frequency.
How does the proposed strategy achieve cost parity or cost advantage against legacy deterministic scheduling, and what are the quantified trade-offs in TES energy configuration?
The proposed strategy achieves cost advantage by resolving the TES reserve interval into a minimum expected cost dispatch, where the minimum expected cost corresponds to the system optimal irradiance operating point. Legacy deterministic scheduling either over-reserves TES—inflating storage cost because capacity is underutilized—or under-reserves TES—incurring loss-of-load shutdown risk. The Beta distribution confidence interval sensitivity analysis quantifies the trade-off: cloudy conditions require the widest reserve margin (relative uncertainty 192.10%, variance 0.0880), while clear-sky sparse-cloud conditions permit the narrowest margin (relative uncertainty 76.96%, variance 0.0197). By matching the TES reserve to the weather-specific probability distribution, the proposed strategy avoids both failure modes, achieving coordinated optimization of long-timescale TES energy configuration and dispatch cost across multiple uncertainty scenarios.
What are the operational thresholds for switching between deterministic and probabilistic scheduling within the 72 h horizon, and how does the system handle weather type transitions?
The operational threshold is fixed at 48 h: the first 48 h are treated as deterministic scheduling with accurate forecast data, and the final 24 h are treated as probabilistic interval scheduling with Beta-distributed irradiance data. Weather type transitions within the 24 h probabilistic window are handled by the lower-level PSO, which performs economic dispatch according to weather transition probabilities. The upper level reserves TES energy to hedge against weather uncertainty across the transition. The system optimal irradiance operating point is identified as the minimum expected cost solution across the probabilistic interval, with the four weather types—clear-sky sparse-cloud (α=6.5, β=2.3), cloudy (α=β=0.92), overcast (α=3.8, β=4.4), and rain-snow (α=1.5, β=3.5)—providing the discrete probability distributions for the transition matrix.
