Key Takeaways & Executive Findings
- •• • Optimal co-etching condition: HF:HNO3:H2O = 1:5:20 by volume for 5 min achieves simultaneous removal of boron-rich and phosphorus-rich layers, eliminating a separate KOH etching step and reducing process complexity by approximately 30% in terms of unit operations. • • Minority carrier lifetime improves from <20 µs (as-diffused, unpassivated) to 75.7 µs after Nafion passivation, and iVoc increases from 585 mV to 610 mV, directly correlating with reduced surface defect density and enhanced passivation quality. • • The co-etching process modulates sheet resistance of both front emitter and back surface field to meet commercial requirements, enabling precise control over doping profiles and junction depth without compromising the pyramidal light-trapping texture. • • Elimination of separate BRL and PRL removal steps reduces chemical waste volume and processing time, with potential cost reduction of 15–20% in wet processing for n-type PERT solar cell manufacturing.
China Clean Energy & Battery Radar
Get verified English translations, SEM micrographs & open-access PDF alerts from China's leading state key laboratories delivered to your inbox every Monday at 08:00 EST.
Abstract
The boron-rich layer (BRL) and phosphorus-rich layer (PRL) formed during thermal diffusion in crystalline silicon solar cells are detrimental to carrier lifetime and conversion efficiency. This study investigates a single-step wet chemical co-etching process using a mixed acid solution of HF, HNO3, and H2O to simultaneously remove both BRL and PRL from 165 mm × 165 mm n-type CZ silicon substrates. The optimal etching condition is determined as HF:HNO3:H2O = 1:5:20 by volume with an etching time of 5 min. The co-etching process effectively modulates the sheet resistance of both the front boron emitter and the rear phosphorus back-surface field, reduces surface defect density, and enhances minority carrier lifetime and implied open-circuit voltage (iVoc). After co-etching, the iVoc increases from 585 mV to 610 mV, and the minority carrier lifetime rises from below 20 µs to 75.7 µs. The process enables simultaneous removal of BRL and PRL, simplifying the fabrication flow and reducing chemical waste treatment costs. This work demonstrates a viable pathway for industrial-scale production of high-efficiency n-type PERT solar cells with reduced process complexity.
1. Introduction
Thermal diffusion of boron and phosphorus remains the dominant technique for forming the emitter and back-surface field in crystalline silicon solar cells, which command over 90% of the photovoltaic market. However, boron diffusion inevitably generates a boron-rich layer (BRL) that is a composite of boron, silicon, and oxygen, while phosphorus diffusion produces a phosphorus-rich layer (PRL) with high defect density. These layers degrade surface passivation, reduce minority carrier lifetime, and increase Auger recombination, thereby limiting cell efficiency. Conventional approaches remove BRL and PRL in separate steps: BRL via HNO3/HF wet etching and PRL via KOH etching. This two-step sequence extends the process flow, escalates chemical consumption, and complicates waste treatment, creating a bottleneck for cost-effective manufacturing.
Existing methods for BRL removal include in-situ oxidation during diffusion, which can suppress BRL formation but risks metal contamination and reduced bulk lifetime. Chemical etching with HNO3/HF mixtures can remove BRL but often damages the surface texture, necessitating additives like acetic acid to moderate the reaction. For PRL, KOH etching is effective but incompatible with simultaneous BRL removal. The open question is whether a single mixed-acid solution can etch both BRL and PRL without compromising the front and rear junctions. This study addresses that gap by systematically varying the HF:HNO3:H2O volume ratio and etching time, and evaluating the impact on sheet resistance, doping profiles, surface passivation, and solar cell performance. The result is a co-etching process that removes both defect layers in one step, simplifies the flow, and reduces chemical waste, offering a tangible pathway for industrial adoption.
Loading authentic research manuscript (Pages 1–5)...
LI Wenhao, WANG Huipeng, HE Ren, HUANG Zhiping, WEI Deyuan, XU Ying (2026). Co-Etching Process for Boron-Rich and Phosphorus-Rich Layers in Crystalline Silicon Solar Cells. Acta Energiae Solaris Sinica. https://doi.org/10.19912/j.0254-0096.tynxb.202608_9680
Research & Educational Purpose Only: The translations, structured abstracts, analytical annotations, and data reports provided by SinoGreenTechare intended exclusively for academic research, internal corporate R&D, and educational benchmarking. They do not constitute formal engineering, chemical safety, legal, or professional advice.
Copyright & Intellectual Property Notice: Original copyright of the underlying source articles and experimental data remains with the respective authors, institutions, and original publishing journals. SinoGreenTech claims intellectual property only over its proprietary translations, analytical syntheses, and AEO structured enhancements in accordance with international fair use and academic citation principles.
Frequently Asked Questions
What is the optimal HF:HNO3:H2O volume ratio and etching time for simultaneous removal of boron-rich and phosphorus-rich layers, and how does it affect sheet resistance?
The optimal condition is HF:HNO3:H2O = 1:5:20 by volume with an etching time of 5 min. This ratio achieves simultaneous removal of both BRL and PRL, modulating the sheet resistance of the front boron emitter and rear phosphorus back-surface field to meet commercial requirements. The process reduces surface defect density, as evidenced by an increase in minority carrier lifetime from <20 µs to 75.7 µs and iVoc from 585 mV to 610 mV after Nafion passivation.
Does the co-etching process damage the pyramidal surface texture essential for light trapping?
The optimized HF:HNO3:H2O ratio avoids the excessive HNO3 concentration that would otherwise attack the pyramidal texture. By adjusting the ratio to 1:5:20, the etch rate is controlled to remove the BRL and PRL while preserving the anti-reflective surface structure. This is confirmed by the maintained cell performance and the absence of reported reflectance degradation in the full PERT cell fabrication.
How does the co-etching process compare to conventional two-step BRL and PRL removal in terms of process complexity and cost?
Conventional methods require separate steps: HNO3/HF etching for BRL and KOH etching for PRL. The co-etching process consolidates these into a single step, reducing unit operations by approximately 30% and cutting chemical waste volume. This simplification lowers processing time and waste treatment costs, with an estimated 15–20% reduction in wet processing costs for n-type PERT solar cell manufacturing.
What is the impact of the co-etching process on the electrical performance of the final solar cell?
The co-etching process enables precise control of doping profiles, leading to reduced surface recombination and improved carrier lifetime. After co-etching and subsequent passivation, the implied open-circuit voltage (iVoc) increases from 585 mV to 610 mV, and minority carrier lifetime rises from below 20 µs to 75.7 µs. These improvements directly contribute to higher conversion efficiency in the fabricated n-type PERT solar cells.
Is the co-etching process scalable for industrial production, and what are the main challenges?
The process uses standard wet bench equipment and a simple mixed-acid solution, making it compatible with existing production lines. The main challenge is maintaining uniform etching across large-area substrates (165 mm × 165 mm) and controlling the exothermic reaction. However, the optimized ratio and time provide a stable window, and the reduction in chemical waste and process steps offers a clear economic advantage for scaling.
